Infrared inoculation loop sterilizer - annealing without flame! The SteriMax electrical annealing system is ideal for annealing inoculation loops, needles and instruments.
Ideal for laboratories and safety workbenches where gas and open flames must not be used.
SteriMax
with 7-fold angle adjustment Residual
heat display Storage
for 3 instruments
- Made entirely of stainless steel
- Long - Life double tube system
- Sterilization time 5-7 seconds
- Self-fixing angle adjustment
Resistant
The unique double tube system made of robust quartz glass and wear-resistant ceramic reaches the optimal annealing temperature of 900 ° C (1650 ° F) after only a few minutes. To anneal the inoculation loop is simply held in the ceramic glow tube. The inoculation loop is sterilized after 5-7 seconds *. An integrated splash guard ensures more safety when handling pathogenic material. Even dirt is not a problem. The ceramic glow tube can be easily removed from the quartz glass heating element for separate cleaning.
Flexible and secure.
The exclusive angle adjustment enables a self-fixing position of the glow tube. The low and stable housing allows comfortable working; the unique design protects the work surface from dirt. Outstanding passive safety: after prolonged use, a residual heat indicator signals that the surface of the glow tube is hot, thus protecting against burns.
All around made of stainless steel, the SteriMax also withstands extreme laboratory conditions.
Specification :
Double pipe system:
Length 118 mm ceramic glow tube Ø 15 mm quartz glass heating element Ø 21 mm
Angular positions:
7
Safety device:
Residual heat indicator
Annealing temperature :
900 ° C - 950 ° C (1650 ° F - 1742 ° F)
Sterilization time:
5-7 seconds *
Heating time:
700 ° C / 11 minutes
800 ° C / 14 minutes
900 ° C / 24 minutes
Heat radiation:
Heating a stainless steel surface above with still air and 20 ° C room temperature
distance: 20 cm: 65 ° C, 30 cm: 34 ° C ,40 cm: 28 ° C
