Range | 38 µm to 125 mm |
Drive / sieving motion | electromagnetic |
Max. batch / feed capacity | 3 kg |
Max. number of sieves | 8 full height / 16 half height (200 mm / 8 |
Amplitude | ~ 1.6 mm* fixed |
Speed | 3,000 min-1 at 50 Hz |
Time display | analog, 0 - 60 min, continuously |
Suitable for dry sieving | yes |
Sieve diameter | 100 / 200 mm 3 |
Min. number of sieves | 2 full height 200 mm / 8 |
Clamping device | clamping belt system (included) |
Model | benchtop |
Protection code | IP 20 |
Electrical supply | different voltages available |
Power connection | 1-phase |
W x H x D | 262 x 126 mm |
Net weight | ~16 kg |
Standards | CE |
